About the MK-X150

The MK-X150 was developed after years of research in Africa and South-east Asia considering climate and environment conditions of these regions.

The major advantages of MK-X150 Series over other similar systems are:

  • All components are autonomous which makes the product easy to maintain and repair. Faulty parts are easily replaced when needed. Similar product have system components on a single board making it more costly and difficult to replace or repair faulty parts.

  • You can easily upgrade the battery capacity by adding additional batteries in parallel, just by connecting the battery cables to the terminal battery connector on the MK-X150 Solar box.

  • The Charge controller is able to charge additional external batteries.

  • There as been reports in Africa and Asia where ants and other bugs have been found to be the cause of major damage to solar product. The MK-X150 is anti-insect and ants-proof.

Setup and Operation

  • Place solar panel outside where it can get direct sunlight.
  • Connect solar cable to solar panel A and connect the other end B to solar system (Diagram 1).
  • Switch On electrical circuit breaker C.
  • Switch On solar system Power switch D
  • Connect devices (TV, LAPTOP ETC) to power socket E and F (220V OUTPUT).
  • Connect male socket H to female socket G to power your caravan, boats, trucks, etc.(220V)
  • Use your phone to connect to Blue tool BT1 censor I and use your solar App to connect to the BT1 blue tool.
  • Connect 12V devices (12V LED LIGHT BULBS, 12V SOLAR WATER PUMP, 12V FANS, 12V REFRIGERATOR, etc.) to 12V connector J
  • Connect your phone to USB charging point K
  • External battery connector L
  • External battery connector cable M
